TORD4B-63 type b rcd ev charger RCCB RCD 2P 63A 30mA Type B RCD 6KA
TORD4B-63/2/10/003
Regular price €65,00 €85,00 Sale price
Notice：Free shipping, Door to Door with fast delivery.😘
Tip: Price excluding VAT
General:
This is B Type Residual Current Circuit Breaker Type B RCCBs, in addition to normal AC, can detect high frequency AC and pure DC earth leakage currents. Reducing the risk of fire and/or electrocution through automatic disconnection of the electrical supply relies on the selection of the correct type of RCCB. View 'B' Type Applications requiring 'B' types include: EV & PV installations Frequency converters UPS installations High-frequency power converters Building site power supply cabinets
Technical Data:
|
Model Name |
TORD4B-63 |
|
Model |
Electromagnetic Type |
|
Residual Current characteristic: |
B type |
|
Pole No: |
2P /4P |
|
Rated making and breaking capacity |
630A |
|
Rated current（A） |
63A |
|
Rated voltage |
230V/400V |
|
Rated frequency |
50/60Hz |
|
Rated residual operating current |△(A): |
0.03 |
|
Rated residual non operating current |△ no: |
0.5|△ n |
|
Rated conditional short-circuit current inc: |
6kA |
|
Rated conditional residual short-circuit current |△c: |
6kA |
|
Tripping duration: |
Instantaneous tripping ≤0.1s |
|
Residual tripping current range: |
0.5||△n~|△n |
|
Electro-mechanical endurance |
≥15000 cycles |
|
Connection capacity: |
Rigid conductor 25mm⊃2; |
|
Connection terminal |
Screw terminal |
|
Fastening torque |
3.5 Nm |
|
Installation |
On symmetrical DIN rail 35mm |
